Guard Patrol Management System Shockproof Black 215 Grams Mass
Touch Reading Stick Patrol Checkpoint Data Downloader
Overview
HUA-101X is a kind of 215 grams patrol checkpoint system touch
reading stick. The HUA-101X reading stick is shockproof, waterproof
and the colors of it and HUA-101XT data downloader are both black.
Downloader's mass is 140g. HUA-101X reading stick and HUA-101XT
downloader are in ergonomic structure hammer style. It is very
suitable for seurity patrolmen to hold and to use when they patrol.
Since product type is touch induction type, the stick will read the
button checkpoints from the zero cm distance. The battery is 3.6V
built-in lithium battery and a full charge can support about 15
full days continuously reading tags. Each checkpoints has been
installed with the touch button, from which the patrolman may read
the checkpoints with HUA-101X patrol-stick. The patrol-stick then
will generate records, with each containing the code number and
time of the touch button checkpoints.
Technical data sheet
Touch Guard Tour
Reader | Dimension | 180*32*24(mm) |
| Weight | 215g |
| Color | Black |
| Storage Capacity | 16MB, can store up to 10,000 records |
| Battery | 3.6V built-in lithium battery |
| Read mode | touching |
| Read distance | 0cm, must touch checkpoint |
| Read indication | light and vibration |
| Read time | less than 1s |
| Software | Stand-alone, free |
| Downloader | Dimension | 10×10×3.5 cm |
| Weight | 140g |
| Color | Black |
| Communication Port | USB |
| Physical | Alloy |
| Power | 6V , 50hz |
| Function | Communicate with computer via USB port, high-speed and stable
transmission and data transfer... |
|
Checkpoint
Touch Button | Install on wall or equipment etc as a checkpoint. | Physical: Electronic chip stored in the stainless steel case that
is water-resistant.
Type: 1990A-TM iButton, global unique ID.
Life-span: > 20 years |
|
|
Checkman
Touch Button | Used as patrolman identification. |
|
|
Usage
(1) Used for patrolling
(2) Widely used in Communities, Hospitals, School, Construction
site, Industries, etc.
Package
One set includes a patrol reader HUA-101X, and 101XT Downloader,
and one cable, with free cloud management software.
* There are 4 options for charger type. Please contact me to
select.*
Shipping
How HUA-101X works
First step: Install checkpoints at patrol locations
Second step: Get guard ID tags information
Third step: Set patrol schedule on the software
Fourth step: Start to patrol
Last step: View reports on the software, Computer query
8. FAQ
Q: Can it work well in my side?
A: Of course it can. It's carefully tested before delivery to
ensure it's with good quality and function.
Q: Do you charge for your software? How?
A: We provide standard cloud software in English based on our own
server free of charge.
Q: Do you offer other versions of software besides English?
A: Yes, we could customize standard software for you in othe
languages for free.
Q: Could you please send me more details?
A: My pleasure, Just feel free to contact us
